Fluid Controls CV-700T F x F 1/2 in. Stainless Steel Check Valve - 3500 PSI, 12 GPM, PTFE
Brand:
Mfr. Model #:
CV-700T
KR Part #:
CV0071T
Weight:
0.31 lbs
In Stock
Stainless steel material check valve with a PTFE o-ring. 1/2" x 1/2" female ports.
Technical Specifications
Max PSI: 3500
Max Temperature: 170 degrees F
Inlet Port: 1/2 inch
Max GPM: 12
Product Description
1/2" F x 1/2" F Non-Return Valve with PTFE Seal
The Fluid Controls CV-700T check valve allows you to keep water and fluids flowing in a single direction within your high-pressure system.
This one-way valve has 1/2" female ports, is rated for 12 GPM, and has a maximum pressure tolerance of 3500 PSI. Stainless steel body with PTFE o-ring.
Specifications:
- Female 1/2" x 1/2" ports
- 12 GPM flow rate
- 3500 PSI maximum pressure
- 10 PSI open pressure
- 170° Fahrenheit maximum temperature
- PTFE o-ring
- Stainless steel construction
Features:
- Leak-proof operation
- Valve is rebuildable
- Unique V type seat and floating piston guide provides a continuous wiping.
