Spraying Systems 23504-10 Power Jet Nozzle Cartridge - Orifice Number 10, 6.2 GPM, 1500 PSI
Brand:
Mfr. Model #:
23504-10
KR Part #:
SNPJC10
Weight:
0.05 lbs
Availability:
1
Low Inventory Get It Today
A spray nozzle cartridge for Power Jet nozzles. Features a #10 orifice. Handles a maximum flow rate of 6.2 GPM at 1500 PSI.
NOTE: This is a clearance item with limited inventory. All sales final - no returns.
Technical Specifications
Max PSI: 1500
Max GPM: 6.2
Min GPM: 3.6
Min PSI: 500
Type: Nozzle/Tip
Product Description
#10 Orifice - Polyphenylene Sulfide Nozzle Cartridge
The Spraying Systems 23504-10 is a cartridge that is placed Power Jet spray nozzles. It's orifice number determines the GPM range when used at the specified pressure. Cartridge is made with polyphenylene sulfide due to it's high temperature tolerance. This model features a number 10 orifice with a minimum flow rate of 3.6 GPM at 500 PSI and a maximum flow rate of 6.2 GPM at 1500 PSI.
This is a clearance item with limited inventory. All sales final - no returns.
Specifications:
- Compatible Nozzle: 23500-1/4
- Orifice Size: #10
- Capacities GPM:
- 3.6 GPM at 500 PSI
- 3.8 GPM at 600 PSI
- 4.2 GPM at 700 PSI
- 4.4 GPM at 800 PSI
- 5.0 GPM at 1000 PSI
- 6.2 GPM at 1500 PSI
