Dema A413P.2 Brass 3/8 in. Pilot-Piston Low Pressure Valve 12V
Brand:
Mfr. Model #:
A413P.2
KR Part #:
SOD413P12
Weight:
2.20 lbs
Availability:
1
Low Inventory Get It Today
This A413P pilot operated piston solenoid valve has a maximum pressure of 150 PSI.
Prop 65
Technical Specifications
Max PSI: 150
Product Description
3/8" Normally Closed Solenoid Valve - 150 PSI
This is a pilot-piston operated, general purpose solenoid valve. It is designed for use with water, air, light oil, and noncorrosive fluids. Do not use for gas and other hazardous or explosive fluids.
With this A413P model, the stem and plunger assembly opens the port. This releases pressure on top of the piston, which opens the main valve port. Dema pilot-piston solenoid valves are available for 3/8" to 1" pipes: see Related Products section.
Size: 3/8" NPT
- Rated for 200 degrees Fahrenheit fluid temp. and 120 degrees Fahrenheit ambient temp.
- CV flow factor: 2.00
- Orifice diameter: 0.313
- Brass construction
- Stainless steel seat
- Teflon seal
- 12V
- Maximum pressure: 150 PSI
- Normally closed
WARNING: This product can expose you to chemicals including Lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm (For more information go to www.p65warnings.ca.gov).
