Mosmatic 34.853 Nickel Plated Brass High Flow Swivel Rotary Union DGE - G1 1/2 Inch NPTF, G2 1/2 Inch NPTM, NW 1/2 Inch, 4000 PSI, 30 RPM

Brand:
Mfr. Model #:
34.853
KR Part #:
SWM34853
Weight:
1.25 lbs
Usually Ships in 2 Weeks
Add to Cart for Price

This swivel is compatible with high flow rate and low rpm applications. Made with nickel-plated brass for corrosion resistance. Designed to tolerate a maximum pressure of 4000.




Technical Specifications

Max PSI: 4000
Inlet Port: 1/2 inch
Outlet Port: 1/2 inch
Max Temperature: 250 degrees F

Product Description

This is a swivel used in high flow and low rpm applications. Made with nickel-plated brass for corrosion resistance. Designed to tolerates a maximum pressure of 4000.

 Specifications:

  • Pressure: 4000 PSI (27.5 MPa)
  • Temperature: 250°F
  • Max RPM: 30 RPM
  • Body: Nickel Plated Brass
  • Inner Part: Stainless Steel
  • Seal: O-ring NBR (optional: EPDM or FKM
  • Bearing: 1x Thrust Ball Bearing, 1x Radial Ball Bearing
  • Throughput: pH 3-12
  • Medium: Filtered 10 Microns, Compressed Air (290 PSI)

Features:

  • Maintenance free
  • Sealed stainless steel bearings
  • High flow
  • Applications:
  • High Flow
  • Low Rpm
  • Automatic Car Wash Systems
  • High Pressure Hose Reels

Dimensions:

  • G1 (F): 1/2" NPTF
  • G2 (M): 1/2" NPTM
  • NW: 1/2"
  • SW1: 0.87
  • SW2: 1.38
  • L1: 3.15
  • L2: 2.17
  • L3: 0.59
  • D1: 1.65
  • Weight: 1.25 oz
