Mosmatic 35.153 Nickel Plated Brass DGF Rotary Union Swivel - 3/8 Inch NPTF, 3/8 Inch NPTM, 4000 PSI
Brand:
Mfr. Model #:
35.153
KR Part #:
SWM35153
Weight:
0.75 lbs
A rotary union swivel made with nickel plated brass. Resist's corrosion and requires minimal maintenance. Handles a maximum pressure of 4000 PSI and maximum speeds of 1000 RPM.
Technical Specifications
Inlet Port: 3/8 inch
Outlet Port: 3/8 inch
Max PSI: 4000
RPM: 1000
Product Description
Triple Bearing Rotary Union
Mosmatic DGF 35.153 is made with nickel plated brass that endures a maximum pressure of 4000 PSI and resists corrosion. Utilizes a high-speed triple bearing system for high-speed applications at a maximum of 1000 RPM. Engineered to require minimal maintenance during operation. Used in high pressure cleaning technology, parts washers, tire cleaners and self-rotating applications.
Specifications:
- Pressure: 4000 PSI (27.5 mpa)
- Temperature: 90°F (At 1'000 RPM), 250°F (At 30 RPM)
- RPM: Max. 1,000 RPM
- Body: Brass, Nickel Plated
- Inner Part: Stainless Steel
- Seal: O-ring NBR (optional: EPDM or FKM)
- Bearing: 2x Radial Ball Bearings, 1x Thrust Ball Bearing
- Throughput: pH 3-12
- Medium: Filtered 10 Microns, Compressed Air (290 PSI)
Features:
- High Speed Triple Bearing System
- Body Design for Easy Installation
- High Precision and Quality
- Maintenance Free
Applications:
- High Pressure Cleaning Technology
- Parts Washers
- Tire Cleaners
- Self-Rotating Applications
Dimensions:
- G1: 3/8" NPTF
- G2: 3/8" NPTM
- NW: 1/4"
- SW1: 0.87
- SW2: 0.75
- L1: 1.49
- L2: 0.47
- Weight: 10.4 oz
