Mosmatic 40.009 Nickel Plated Brass 90 Degree WDG Swivel Rotary Union - 1/4 Inch F x M, 4000 PSI, 30 RPM

Brand:
Mfr. Model #:
40.009
KR Part #:
SWM40009
Weight:
0.49 lbs
Low Stock Warning
Add to Cart for Price
A swivel made with nickel plated brass. Designed for maintenance free operation. Equipped with  G1/4 F and G1/4 M connections.



Technical Specifications

Max PSI: 4000
RPM: 30
Max Temperature: 250 degrees F
Inlet Port: 1/4 inch
Outlet Port: 1/4 inch

Product Description

4000 PSI Ceiling Boom Swivel

The Mosmatic 40.009 rotary union is constructed using brass with a nickel-plated coating and a stainless-steel inner part. Equipped with NBR seals. Handles a maximum pressure of 4000 PSI. Endures a maximum temperature of 250°F. Ideal for applications involving ceiling booms, high-pressure hose reels and high-pressure cleaners.

Specifications:

  • Pressure: 2200 PSI (15 mpa), 4000 PSI (27.5 Mpa)
  • Temperature: 200°F - 250°F
  • RPM: Max. 30 Rpm
  • Body: Brass, Nickel Plated
  • Inner Part: Stainless Steel
  • Seal: O-Ring NBR (Optional: EPDM Or FKM)
  • Bearing: Sliding Bearing
  • Throughput: Ph 3-12
  • Medium: Filtered 10 Microns, Compressed Air (290 Psi)

Applications:

  • Ceiling Booms
  • High Pressure Hose Reels
  • High Pressure Cleaners

Dimensions:

  • G1 (F): G1/4
  • G2 (M): G1/4
  • NW: 1/4"
  • H: 1.02
  • L1: 1.77
  • L2: 1.14
  • L3: 1.73
  • L4: 0.96
  • L5: 0.33
  • L6: 0.25
  • SW: 0.87
  • Weight: 9.8oz
