Mosmatic 56.163 Nickel-Plated Brass DYL 3/8 in. x 3/8 in. Rotating Swivel - 4000 PSI
Brand:
Mfr. Model #:
56.163
KR Part #:
SWM56163
Weight:
0.50 lbs
Rotating DYL straight swivel made with nickel-plated brass. Built with 3/8 inch inlet and outlet ports. Survives a maximum pressure of 4000 PSI.
Technical Specifications
Max PSI: 4000
Max Temperature: 250 degrees F
RPM: 2000
Inlet Port: 3/8 inch
Outlet Port: 3/8 inch
Product Description
Single-Flow 3/8" NPT x 3/8" G Self-Rotating Swivel
The Mosmatic 56.163 self-rotating swivel is made with brass and has 3/8" ports. It is rated to handle up to 4000 psi, 2000 rpm, and 250° Fahrenheit.
Rotary unions allow you to transfer fluids from stationary items like hose and piping to rotating devices in car wash systems, industrial machine cleaning, and surface cleaners.
- Inlet: 3/8" NPT (F)
- Outlet: 3/8" NPT (M)
- Maximum Pressure: 4000 PSI
- Maximum Speed: 2000 RPM
- Maximum Temperature: 250° Fahrenheit
- Body Diameter: 2.36"
- Body Construction: Brass w/ nickel plating
- Type: DYL
- Two radial ball bearings
- One thrust ball bearing
- Carbide seal
- Self-rotating
- Standards: ISO 9001
- Throughput Medium: pH 3-12 filtered 10 microns compressed air
- Seal failure warning through weep holes
