Fluid-O-Tech PA 810F Stainless Steel Rotary Vane Pump - 4.4 GPM, 260 PSI, 1/2 Inch NPFT Ports
Brand:
Mfr. Model #:
PA810F
KR Part #:
FTPA810F
Weight:
4.14 lbs
Availability:
1
Low Inventory Get It Today
This rotary vane pump is made with stainless steel and carbon graphite. Great for car washes, reverse osmosis, and cooling systems. Female threaded 1/2 NPT ports.
Product Description
800 Series Vane Pump
Fluid-O-Tech's rotary vane pumps are crafted with stainless steel. High impact carbon graphite is used for the pumping chamber and the vanes. This pump is mounted using a 3-bolt flange. Port measure 1/2 NPT female threaded ports.
Specifications:
- Item: Rotary Vane Pump
- Inlet/Outlet NPTF (In.): 1/2 in
- Max. Flow (GPH): 264
- Min. Flow Rate (GPH): 245
- Relief Pressure Max. (PSI): 260
- Max. Pressure (PSI): 260 psi
- Body Material: Stainless Steel
- External Relief: Not Required
- By-Pass: No
- Mounting: 3-Bolt Flange
- Max. Temp. (F): 158 Degrees F
- Shaft: Stainless Steel
- GPH of Water @ 50 PSI: 261
- GPH of Water @ 100 PSI: 259
- GPH of Water @ 150 PSI: 256
- GPH of Water @ 200 PSI: 253
- GPH of Water @ 250 PSI: 245
- GPH: 264
- Compliance: NSF
