Spraying Systems CP4916-12 Stainless Steel Orifice Plate 12 for TeeJet Assemblies
Brand:
Mfr. Model #:
CP4916-12
KR Part #:
SNCP4916-12
Weight:
0.05 lbs
Usually Ships in 2 Weeks
Stainless steel orifice plate for flow-regulating TeeJet assemblies. Number 12 orifice option. Always insert the plate with the number-marked side facing the outlet.
NOTE: Image is for representation only. Please check all specifications carefully before buying.
NOTE: Image is for representation only. Please check all specifications carefully before buying.
Product Description
No. 12 SS Orifice Plate
The Spraying Systems CP4916-12 Orifice Plate is made of stainless steel and has a .012" orifice. This component is used with TeeJet assemblies and controls the flow rate.Specifications:
- #12 (.012" orifice)
- Stainless steel construction
- 5-60 PSI
- Use with Spraying Systems TeeJets
- GPM @ 5 PSI - .007 GPM
- GPM @ 10 PSI - .010 GPM
- GPM @ 20 PSI - .013 GPM
- GPM @ 30 PSI - .016 GPM
- GPM @ 40 PSI - .019 GPM
- GPM @ 50 PSI - .021 GPM
- GPM @ 60 PSI - .023 GPM
