Procon 102E100R11BC Series 2 Brass Rotary Vane Pump 100 GPH
Brand:
Mfr. Model #:
102E100R11BC
KR Part #:
PP1504VXH
Weight:
3.00 lbs
Usually Ships in 3 Weeks
Pump has a brass housing and 3/8" NPT ports. Note: clamp-on mounting style pictured. This is a bolt-on pump.
Technical Specifications
Max PSI: 250
RPM: 1725
Horsepower: 0.50
Inlet Port: 3/8 inch
Max GPM: 1
Product Description
Series 2 Rotary Vane Pump
This Procon Series 2 brass model has the same features as the Series 1, with the exception of the integral strainer. Primarily used for espresso/coffee applications, and welding is the secondary application. Other applications include carbonated water, reverse osmosis, beer chillers, pesticide systems, and solar applications.
Dimensions: 3.56" x 3.49" x 3.86"
- Bolt on pump with single flat drive
- Brass housing
- 100 GPH
- Fluorocarbon elastomer
- Clockwise rotation
- Standard clearance
- Plastic, high temperature, solid valve
- 60-99 PSI pressure range; Default setting at 99 PSI
- Dry weight: approximately 3 lbs.
- Port size: 3/8" NPT inlet and outlet
- Procon part #102E100R11BC
