Hypro SG1001.58C Standard Back Mount Dry Pressure Gauge - 100 PSI, 1/8 MNPT
Brand:
Mfr. Model #:
SG1001.58C
KR Part #:
HYPG-100158CD
Weight:
0.01 lbs
GTIN:
634332041808
Availability:
4
Plastic pressure gauge with an aluminum white background and an acrylic face. 100 PSI, 1/8" NPT, 1.5" dial. NOTE: Image is shown for illustrative purposes. The dial on the Hypro SG1001.58C Pressure Gauge goes up to 100 PSI.
Technical Specifications
Max PSI: 100
Inlet Port: 1/8 inch
Product Description
Center Back Mount 100 PSI Pressure Gauge
The Hypro SG1001.58C Pressure Gauge is a plastic case gauge with an acrylic face. It has a 1/8" male NPT connection and a 1 1/2" dial. Used in applications up to 100 PSI and mounted from the center back side.
Part of the SG Series from Hypro, this gauge is designed for use with air, gas, oil, water, and other materials that are non-corrosive to brass and bronze.
Specifications:
- 100 PSI
- 1/8" MNPT brass connection stem
- Center back mount
- Dial: 1 1/2" with white aluminum background
- Case Material: Plastic
- Movement: Brass
- Bourdon Tube: C-shaped copper alloy
- Pointer Material: Black-enameled aluminum
- Window Material: Acrylic
- Accuracy: ASME/ANSI B40.1 Grade B (3-2-3%)
- U-clamp included for mounting
- This is a dry gauge with no liquid to cut down on vibration
