Mosmatic 35.453 Nickel Plated Brass Rotary Union 90 Degree Swivel - 3/8F x 3/8M
Brand:
Mfr. Model #:
35.453
KR Part #:
SWM35453
Weight:
0.80 lbs
Nickel plated brass body rotary union swivel with stainless steel inner components. Tolerates applications up to 4000 PSI pressure. Has 3/8" FNPT x MNPT connections.
Technical Specifications
Max PSI: 4000
Max Temperature: 250 degrees F
Product Description
Nickel Coated 90° Brass Rotary Swivel
The Mosmatic 35.453 Rotary Union Swivel is made with nickel plated brass and has 3/8" female NPT x 3/8" male NPT connection points. This quality swivel is used in high-pressure applications like car washes, industrial cleaning, parts washing, and more.
Technical Specifications:
- 4000 PSI maximum pressure
- 3/8" FNPT x 3/8" MNPT
- 250° Fahrenheit maximum temperature (90° Fahrenheit at 1000 RPM)
- Nickel plated brass body
- Stainless steel inner parts
- NBR O-ring seal
- 2x radial ball bearings, 1x thrust ball bearing
- 3-12 pH throughput
- Medium: filtered 10 microns, compressed air (290 psi)
Features:
- Maintenance free
- High precision and quality
- High speed triple bearing system
- Body designed for easy installation
